Euro3 5cbm mini Lpg Gas Tank Truck with refilling system

FOB Reference Price:Get Latest Price
US $23,995-24,560 / Piece | 1 Piece/Pieces Lpg Gas Tank Truck (Min. Order)
Supply Ability:
500 Piece/Pieces per Month Lpg Gas Tank Truck
Port:
SHANGHAI
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Storage:
LPG
Drive Wheel:
4x2
Horsepower:
< 150hp
Transmission Type:
Manual
Fuel Type:
Diesel
Tank Volume:
5001 - 10000L
Engine Capacity:
3856
Dimensions (L x W x H) (mm):
5990x1960x2400
Brand Name:
CLW
Place of Origin:
Hubei, China (Mainland)
Model Number:
CLW5060
Gross Vehicle Weight:
6495
CURB WEIGHT(KG):
3365
HORSEPOWER:
95
MAX SPEED (KM/H):
90
Certification:
ASME , CCC,ISO9001
Tank material:
Q345R , Q370R
Design pressure:
1.61 mpa
Emission standard:
Euro 3 / Euro 5
Driving type:
RHD/ LHD
RHD chassis brand:
dongfeng , howo
Volume:
according to your requirement
Packaging & Delivery
Packaging Details
Lpg Gas Tank Truck
NUDE WITH WAXING TO PROTECT THE LPG TRUCK FROM DAMAGED .
Ship by lCL or Frame container
We will find the cheapest and best transportation way for the lpg products .
Delivery Time
WITHIN 20 WORKING DAYS

--------------------------------------------------------------Lpg Gas Tank Truck ----------------------------------------------------------------------------------

                                                                    ASME , CCC, ISO9001 , SGS

                                                                  Q345R,Q370R ,Q420R,SA516L

                                                                         MADE IN CHINA

                                    Beautiful outlook , perfect craft , rich experience , prfessional working team

                                        LPG STORAGE TANK , LPG TANKER TRUCK , LPG TANKER TRAILER

                                                    TANK 5-200 CBM , TRUCK TRAILER 5 TO 65 CBM

                                            Euro3 5cbm mini Lpg Gas Tank Truck with refilling system

----------------------------------------------------------------------------------------------------------------------------------------------

                                                         LPG TRUCK INFORMATION LETTER

TO : THE CUSTOMER WHO ARE INTERESTED IN THE LPG PRODUCTS

FROM : EVELINE YANG , SALES MANAGER OF CHENG LI SPECIAL AUTOMOBILE CO.,LTD



Dear customer  ,

Thanks for viewing our products . I would like to make a simple presentation of our lpg  truck .

This type use dongfeng LHD  left hand drive chassis .

The size is 5000 L  with dispening machine . People can get the gas from this truck directly .

The loading capacity is 2100kgs .

For 24L lpg cylinder , it can fill about 208 units .

The material is Q345R  . This is a good material for LPG truck with high strength , good Heat resistance .



This truck is for your reference . We can make many different size , chassis brand truck .

Our MOQ is 1 unit .



You are always welcomed to send inquiry or make phone calls , send message .

We will give you the detailed information and try our best to make the products you want .



The lpg truck using life is about 20 years  .

If you have any other information want to know , please ask directly.



Best regards,

-----------------------------------------------------------------------------------------------------------------------------------------------------

Detailed information of the lpg tanker truck

Item

unit

Parameters

Vechicle model

CLW5060 LPG tanker truck

Chassis model

/

EQ1060TJ20D3



Overall dimensions

mm

5990×1960×2400

Curb weight

kg

3365

GVW

kg

Appro*6495

TANK volume

L

5000L

Wheelbase

mm

3300

F/R track base

mm

1506/1466

Approach/departure angle

18/12

Exaust/hp

ml/kw

3856/70

Horsepower

HP

95

Max speed

Km/h

90

Tire specification

/

7.00-16

Traction systerm

/

4*2

NO of axles

/

2

Operation control systerm

Electrically hudraulic

Engine type

CY4102-C3F

Transimission

5-speed with over drive

Electric system

24v

Tanker volume

5500 L

Tanker material

Q345R

Design pressure

1.61Mpa

Gas filling equipment

Qulisty brand

Other equipment

Single fluid, bilateral handling, dual valve box, a single kit, safety valves, thermometers,

 pressure gauges, emergency shut-off valves, fire extinguishers, anti-static belt

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Products Photo view

hot sale lpg truck with dipensing or not

CLW LPG TANK TRUCK

LPG TANKER TRUCK

GLP FILLING TRUCK

GLP TRUCK WITH FIRE EXTINGUISHER

GAS FILLING PUMP

THEROMETER AND PRESSURE GAUGE

GAS INPUT AND OUTPUT VALVE

glp lpg filling gun

 lpg truck

--------------------------------------------------------------------------------------------------------------------------------------------

Package and shipping

Package : nude with waxing to protect the goods from sea water damage .

Shipping : bulk shipment is normal way , frame container is good . If  the truck can be put into the container , we will choose shipping by container .

Carrier : you can find the carrier for us , or we can find carrier by ourselves .

------------------------------------------------------------------------------------------------------------------------------------------

Company simple profile :

CHENG LI SPECIAL AUTOMOBILE CO.,LTD - OUR PROUD FACTORY

LPG GLP TANK TRUCK MANUFACTURE

-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

CERTIFICATE : ASME , CCC, ISO9001 , SGS , PC ,SONCAP

ASME CERTIFICATE

OTHER CERTIFICATES

-----------------------------------------------------------------------------------------------------------------------

YOU CAN CONTACT ME THROUGH BELOW NAME CARD



              U ARE ALWAYS WELCOMED TO VISIT OUR FACTORY AT ANY TIME .

                                                          lpg gas tank truck

_____________________________________________________________________________________

Customer visit

_____________________________________________________________________________________________________________

                                                                   You are always welcome to visit our factory .

Routine: Please take airplane to Wuhan City , Hubei province first ,

                Then we will pick you up . It takes about 1.5 hours from airport to our factory .

Factory Location : Suizhou City , Hubei Province  , China
